Aruba IOn 1430 8G Sw 8 RJ-45 autosensing 10/100/1000 ports Affordable, plug-and-play, unmanaged series for small businesses looking for simple reliable, and low-cost network connectivity, offering Layer 2 Ethernet switching capabilities to help connect printers and access points, without any complicated network configuration or management needed. With fully automated functions, zero ongoing maintenance, and Power over Ethernet (PoE) models, these unmanaged switches deliver simple, reliable connectivity for the smallest SMBs and home offices. Power consumptionMaximum: 12W Idle: 1.7W Input voltage100-240VAC Ports8 RJ-45 10/100/1000 ports Switching capacity16 Gbps Throughput11.90 Mpps Memory and processor128Kb EEPROM; Packet buffer size: 2.0 Mb Power supply nameExternal Power Adapter PoE capability- Operating temperature0°C to 40°C, 32°F to 104°F Management featuresUnmanaged WarrantyLimited Lifetime Warranty with 24x7 phone support for 90 days and chat support for the entire warranty duration. Detailed product description8 RJ-45 autosensing 10/100/1000 ports Weight0.59 kg (1.30 lb) Dimensions13.8 x 15.7 x 3.7 cm (5.43 x 6.18 x 1.46 in)

HPE Networking Instant On Switch 8p Gigabit 1430

General Information

• Product Name: HPE Networking Instant On Switch 1430 8-Port Gigabit

• Product Number: R8R45A

• Differentiator:
  Unmanaged, plug-and-play switch for small businesses and home offices. No configuration required. Provides reliable Gigabit connectivity.

---

Ports

• Total Ports: 8 RJ-45 autosensing ports

• Port Speeds Supported:

  • 10/100/1000 Mbps (IEEE 802.3, 802.3u, 802.3ab)

• Duplex Modes:

  • 10/100 Mbps: Half or Full Duplex

  • 1000 Mbps: Full Duplex only

---

Performance

• Throughput: 11.90 Mpps (Million packets per second)

• Switching Capacity: 16 Gbps

• Packet Buffer Size: 2.0 Mb

• Memory: 128 Kb EEPROM

---

Power

• Power Supply: External Power Adapter

• Input Voltage: 100–240V AC

• Power Consumption:

  • Maximum: 12W

  • Idle: 1.7W

---

Management Features

• Type: Unmanaged (no management interface or configuration needed)

---

Environmental Specifications

• Operating Temperature: 0°C to 40°C (32°F to 104°F)

---

Physical Characteristics

• Dimensions: 13.8 x 15.7 x 3.7 cm

• Weight: 0.59 kg

HPE Networking Instant On Switch 8p Gigabit 1430 (R8R45A) (R8R45A)
I/O ports and slots	8 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Dimensions	138(d) x 157(w) x 37(h) mm
Weight	1.30 lb (0.59 kg)
Processor and Memory	128Kb EEPROM; Packet buffer size: 2.0 Mb
100 Mb latency	< 2.7 Î1Sec
1000 Mb latency	< 1.80 Î1Sec
Throughput (Mpps)	11.90 Mpps
Capacity	16 Gbps
MAC address table size	8192 entries
Reliability MTBF (years)	416.2
Operating temperature	32°F to 104°F (0°C to 40°C)
Operating relative humidity	15% to 95% @ 104°F (40°C) non-condensing
Nonoperating/ storage temperature	-40°F to 158°F (-40°C to 70°C) up to 15000 ft
Nonoperating/ storage relative humidity	15% to 90% @ 149°F (65°C) non-condensing
Altitude	up to 10,000 ft (3 km)
Acoustics	Fanless
Frequency	50Hz/60Hz
AC voltage	100-240VAC
Current	0.3A (12VDC - 1A)
Maximum power rating	12W
Idle power	1.7W
PoE power	-
Power Supply	External Power Adapter
Safety	EN/IEC 60950- 1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 EN/IEC 62368-1, 2nd. & 3rd. Ed. UL 62368-1, 3rd. Ed. CAN/CSA C22.2 No. 62368-1, 3rd. Ed. EN/IEC 60825- 1:2014 Class 1

Emissions	EN 55032:2015/ CISPR 32, Class B FCC CFR 47 Part 15: 2018, Class B ICES-003, Class B VCCI-32, Class B CNS 13438, Class B KS C 9832, Class B AS/NZS CISPR 32, Class B
Immunity	BS/EN 55035, CISPR 35, KS C 9835
Generic	EN 55035, CISPR 35
EN	EN/IEC 61000-4-2
ESD	EN/IEC 61000-4-3
Radiated	EN/IEC 61000-4-4
EFT/Burst	EN/IEC 61000-4-5
Surge	EN/IEC 61000-4-6
Conducted	EN/IEC 61000-4-8
Power frequency magnetic field	EN/IEC 61000-4-11
Voltage dips and interruptions	EN/IEC 61000-3-2
Harmonics	EN /IEC 61000-3-3
Device Management	Unmanaged
Mounting
Mounting positions and supported racking	Supports table-top mounting Supports wall-mounting with ports facing either up or down using base surface mounting holes Supports under-table mounting using base surface mounting holes

HPE Networking Instant On Switch 1430 Series

Key Features

• Unmanaged Layer 2 Gigabit Ethernet switch series ready to deploy in 5-, 8-, 16-, 24-, and 26-port models
• Up to 124W of PoE to power APs, IP Phones, and other IoT devices
• No configuration or management needed
• Plug-and-play with fully automated functions and zero ongoing maintenance
• Quality of Service (QoS) and flow control for improved network efficiency
• Fan-less with Energy Efficient Ethernet for low power consumption
• Class B certified for home office networks (5 and 8 port models)

Standard Features

Simplicity at its Best

• Plug-and-play switches that work right out of the box
• Zero configuration required

Reliable Connectivity

• Connect faster with Gigabit Ethernet speed
• PoE to power devices like APs and IP phones

We've Got You Covered

• Industry-leading limited lifetime warranty and support
• 24 x 7 chat support for entire warranty period

The Networking Instant On Differentiators

Better Together

HPE Networking Instant On products work together to provide a seamless Wi-Fi experience. Wired and wireless voice traffic is prioritized with high QoS priority end-to-end for optimal voice performance.

Industry-Leading Support and Warranty

Expert-level support and industry-leading limited lifetime warranty are also included, along with chat support for the life of the product.

Additional Highlights

• Plug-and-Play: Gigabit Ethernet speeds
• Duplex Support: Half/full-duplex auto-negotiating capability on access ports
• Fiber Uplinks: 26-port model includes two 1G SFP fiber ports for long-distance connectivity
• Simplified Cabling: Auto MDI/MDI-X for cable type detection
• PoE Certification: IEEE 802.3at (Class 4) and 802.3af compliant for APs, IP phones, etc.
• EAPoL Forwarding: Supports 802.1x authentication forwarding
• STP BPDU Forwarding: Ensures proper Spanning Tree operation to avoid loops

Traffic Optimization

• QoS: Prioritizes voice/video traffic via DSCP and IEEE 802.1p
• Flow Control: Helps prevent packet loss at congested nodes
• Jumbo Frame Support: Up to 9216 bytes for large file transfers

Warranty, Service, and Support

HPE Networking Instant On Limited Lifetime Support provides:

• 24x7 phone support for the first 90 days
• 24x7 chat support for the entire warranty period
• Community support for the lifetime of the product PE Networking Instant On Switch 1430 Overview

HPE Networking Instant On Switch 1430 Overview

Technology brings new revenue opportunities, more effective communication, and improved productivity to businesses of all sizes. Yet it also poses daily challenges of configuration and maintenance, especially for small businesses who lack IT support. Small offices and home offices need reliable network connectivity that's fast, configuration-free, and affordable for even the most budget-strapped businesses.

The HPE Networking Instant On Switch 1430 is a plug-and-play unmanaged switch series for small businesses looking for simple, reliable, and low-cost network connectivity. These easy-to-use switches deliver Layer 2 Gigabit Ethernet switching capabilities—at an affordable price point—to help connect and share common resources like printers and access points, without any complicated network configuration.

With plug-and-play operation, fully automated functions, zero ongoing maintenance, and Power over Ethernet (PoE) models, these switches deliver simple, reliable connectivity for the smallest SMBs and home offices.

Model Availability

The HPE Networking Instant On Switch 1430 series includes seven models in both PoE and non-PoE configurations:

• 1 × 5-port model
• 2 × 8-port models
• 2 × 16-port models
• 1 × 24-port model
• 1 × 26-port model with 2 SFP uplinks

PoE Capabilities

The PoE models support up to 30W per port (Class 4 PoE), suitable for powering:

• Access Points
• Surveillance Cameras
• VoIP Phones

Power budgets:

• 8-port PoE model: 64W
• 16-port PoE model: 124W

Designed for Small Business

All switches are fan-less, making them ideal for acoustically sensitive environments such as home offices and meeting rooms. These switches are unmanaged and require no configuration—they are not managed by the HPE Networking Instant On cloud portal.

Model: Hewlett Packard Enterprise Aruba Instant On 1430 8G Switch: Ano Typ switche: Desktop Síťové standardy: *IEEE 802.3 *IEEE 802.3ab *IEEE 802.3az *IEEE 802.3i *IEEE 802.3u *IEEE 802.3x *IEEE 802.3z Datový přenos: *Ethernet 10/100/1000 Kapacita přepínání: 16 Gbit/s Konektory: 8x RJ-45 Napájení: Externí adapter Rozměry: 157 x 37 x 138 mm (Š x V x H) Hmotnost: 0.59 kg Záruka: Doživotní

HPE Aruba Instant On 1430 8G

Neřízený (unmanaged) přepínač z řady 1430 nabízí 8x 10/100/1000 Mbps RJ-45 portů, Plug-and-Play instalaci, plně automatizované funkce a nulovou průběžnou údržbu. Díky snadné obsluze bez složité konfigurace sítě je ideální volbou pro malé podniky a domácí kanceláře, které hledají jednoduché, spolehlivé a cenově přijatelné řešení. Přepínací kapacita switche je 16 Gbps a rychlost směrování činí 11,9 Mpps. Díky prioritizaci na základě DSCP nebo dle standardu 802.1p přepínač zajišťuje plynulý audio a video přenos ve vaší kancelářské síti. Switch lze položit jen tak na stůl, namontovat pod stůl či na zeď. Bezventilátorové provedení zaručuje naprosto tichý chod.

ZÁKLADNÍ SPECIFIKACE

Porty: 8x 10/100/1000 RJ-45

Kapacita switche: 16 Gbps

Rychlost směrování: 11,9 Mpps

Podpora PoE: ne

Rozměry: 157 x 138 x 37 mm

Hmotnost: 0,59 kg

HPE Aruba Networking Networking Instant On Switch 8p Gigabit 1430. Typ přepínače: Nespravované, Přepínač vrstev: L2. Typy přepínaných ethernetových portů RJ-45: Gigabit Ethernet (10/100/1000), Počet přepínaných ethernetových portů RJ-45: 8. Plně duplexní režim. Tabulka MAC adres: 8192 pol., Kapacita přepínání: 16 Gbit/s. Síťové standardy: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Základní, levná řada přepínačů (switch) HPE Aruba Instant On 1430 nabízí neřízené, Gigabit Ethernet přepínače pro malé firmy. Přepínače jsou bez ventilátoru pro tichý provoz a vhodné do kanceláří. Plug-and-play, není potřeba žádná konfigurace ani správa Quality of Service (QoS) pro řízení datového provozu tichý, bez ventilátoru a nízkou spotřebou energie operační teplota: 0°C - 40°C rozměry 138 x 157 x 37 mm

Osmitiportový gigabitový switch s kovovým šasi nabízí spolehlivé a tiché řešení díky pasivnímu chlazení bez ventilátoru. Je vybaven 8× 10/100/1000Mb/s RJ45 porty a je ideální pro malé kanceláře nebo domácí sítě. Díky jednoduchému unmanaged provedení nevyžaduje žádné složité nastavení. Napájení zajišťuje externí adaptér, což usnadňuje instalaci a minimalizuje nároky na prostor. Produkt patří do rodiny HPE Instant On 1430, která je známá svou kvalitou a jednoduchostí. Robustní konstrukce přispívá k dlouhé životnosti a spolehlivému provozu.

Obsah balení

• Zařízení
• Napájecí adaptér 12V / 1A
