ASRock INTEL H510/2DDR4/4SATA3

Specifikace:

H510M-HDV/M.2

• Supports 10th Gen Intel Core™ Processors and 11th Gen Intel Core™ Processors
• Supports DDR4 3200MHz (OC)
• 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1
• Graphics Output Options: HDMI, DVI-D, D-Sub
• 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
• 4 SATA3, 1 x Ultra M.2 (PCIe Gen3 x4 & SATA3)
• 4 x USB 3.2 Gen1 (2 x Rear, 2 x Front)
• 6 x USB 2.0 (4 x Rear, 2 x Front)
• Intel Gigabit LAN

Unique Feature

ASRock Super Alloy - Premium 50A Power Choke - Sapphire Black PCB - High Density Glass Fabric PCB ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update & APP Shop

CPU

- Supports 10th Gen Intel Core™ Processors and 11th Gen Intel Core™ Processors (LGA1200) - 5 Power Phase design - Supports Intel Turbo Boost Max 3.0 Technology

Chipset

- Intel H510

Memory

- Dual Channel DDR4 Memory Technology - 2 x DDR4 DIMM Slots - Supports DDR4 3200 / 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory* - Supports ECC UDIMM memory modules (operate in non-ECC mode) - Max. capacity of system memory: 64GB** - Supports Intel Extreme Memory Profile (XMP) 2.0

*11th Gen Intel Core™ (i9/i7/i5) support DDR4 up to 3200; Core™ (i3), Pentium and Celeron support DDR4 up to 2666. 10th Gen Intel Core™ (i9/i7) support DDR4 up to 2933; Core™ (i5/i3), Pentium and Celeron support DDR4 up to 2666. **Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation.

BIOS

- 128Mb AMI UEFI Legal BIOS with multilingual GUI support - ACPI 6.0 Compliant wake up events - SMBIOS 2.7 Support - CPU Core/Cache, CPU GT, VCCSA, DRAM, VCCIO, VCCST, VCCIN AUX Voltage Multi-adjustment

Graphics

- 11th Gen Intel Core™ Processors support Intel Xe Graphics Architecture (Gen 12). 10th Gen Intel Core™ Processors support Gen 9 Graphics - Graphics, Media & Compute: Microsoft DirectX 12, OpenGL 4.5, Intel Built In Visuals, Intel Quick Sync Video, Hybrid / Switchable Graphics, OpenCL 2.1 - Display & Content Security: Rec. 2020 (Wide Color Gamut), Microsoft PlayReady 3.0, UHD/HDR Blu-ray Disc - Three graphics output options: D-Sub, DVI-D and HDMI** - Supports Triple Monitor - Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Port (Compliant HDMI monitor is required) - Supports HDCP 2.3 with DVI-D and HDMI 2.0 Ports

*Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. **Supports up to 2 displays simultaneously

Audio

- 7.1 CH HD Audio (Realtek ALC897 Audio Codec) - Supports Surge Protection

LAN

- Gigabit LAN 10/100/1000 Mb/s - Giga PHY Intel I219V - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE

Slots

11th Gen Intel Core™ Processors - 1 x PCI Express 4.0 x16 Slot* 10th Gen Intel Core™ Processors - 1 x PCI Express 3.0 x16 Slot* - 1 x PCI Express 3.0 x1 Slot *Supports NVMe SSD as boot disks

Storage

- 4 x SATA3 6.0 Gb/s Connectors, support Intel Rapid Storage Technology 18, NCQ, AHCI and Hot Plug - 1 x Ultra M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) ** Supports NVMe SSD as boot disks* Supports ASRock U.2 Kit

Connector

- 1 x COM Port Header - 1 x SPI TPM Header - 1 x Chassis Intrusion and Speaker Header - 1 x CPU Fan Connector (4-pin) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. - 1 x Chassis Fan Connector (4-pin) * The Chassis Fan supports the Chassis fan of maximum 1A (12W) fan power. - 1 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) * The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. * CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use. - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 1 x Front Panel Audio Connector - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)

Rear Panel I/O

- 1 x PS/2 Keyboard Port - 1 x PS/2 Mouse Port - 1 x D-Sub Port - 1 x DVI-D Port - 1 x HDMI Port - 4 x USB 2.0 Ports (Supports ESD Protection) - 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone

Software and UEFI

Software - ASRock Motherboard Utility (A-Tuning) - ASRock XFast LAN UEFI - ASRock EZ Mode - ASRock Full HD UEFI - ASRock My Favorites in UEFI - ASRock Instant Flash - ASRock Internet Flash *These utilities can be downloaded from ASRock Live Update & APP Shop.

Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar

Accessories

- Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 1 x Screw for M.2 Socket

Hardware Monitor

- Fan Tachometer: CPU, Chassis, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, Chassis, Chassis/Water Pump Fans - CASE OPEN detection - Voltage monitoring: CPU Vcore, +12V, +5V, +3.3V

Form Factor

- Micro ATX Form Factor: 8.9-in x 7.4-in, 22.6 cm x 18.8 cm - Solid Capacitor design

OS

- Microsoft Windows 10 64-bit

Certifications

- FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)

Deska je vybavena grafickými výstupy pro použití s procesory s integrovaným grafickým jádrem. Základní deska grafickou kartu neobsahuje a bez použití odpovídajícího procesoru, budou tyto výstupy nefunkční.

CPU Podpora procesorů 10. a 11. generace Intel Core/ Pentium/ Celeron (patice LGA1200)

Čipová sada Intel H510

Paměť 2x DDR4 paměťový slot, podpora až 64 GB Podpora DDR4 3200/ 2933/ 2800/ 2666/ 2400/ 2133 MHz Dvoukanálová architektura paměti Podpora non-ECC, bez vyrovnávací paměti Podpora ECC pamětí (non-ECC režim) Podpora Intel Extreme Memory Profile (XMP) 2.0

Sloty 1x PCIe 4.0 x16 slot CPU Intel 10. gen. podporuje PCIe 3.0 1x PCIe 3.0 x1

Grafika 1x HDMI port, podporující max. rozlišení 4096 x 2160 při 60 Hz 1x DVI-D port, podporující max. rozlišení 1920 x 1200 při 60 Hz 1x VGA port, podporující max. rozlišení 1920 x 1200 při 60 Hz

Úložiště 4x SATA 6Gb/s port 1x Ultra M.2 slot, M Key, pro jednotky typu 2260/2280 (PCIe 3.0 x4 a SATA režim)

USB 4x USB 3.2 Gen1 (USB 3.0) port (2 porty na zadním panelu, 2 porty dostupné přes interní USB konektor) 6x USB 2.0 port (4 porty na zadním panelu, 2 porty dostupné přes interní USB konektory)

Audio Realtek ALC897 Codec 7.1kanálové High Definition Audio

LAN 1x Intel I219V Gigabit LAN řadič

Interní konektory 1x 24-pin ATX hlavní napájecí konektor 1x 8-pin ATX 12V napájecí konektor 4x SATA 6Gb/s konektor 1x Ultra M.2 slot, M Key 1x USB 3.2 Gen1 (USB 3.0) konektor (podporuje 2x USB 3.2 Gen1 port) 1x USB 2.0 konektor (podporuje 2x USB 2.0 port) 1x 4-pin konektor ventilátoru CPU 1x 4-pin konektor ventilátoru skříně 1x 4-pin konektor ventilátoru skříně/ pumpy vodního chlazení 1x audio konektor předního panelu 1x konektor pro sériový port 1x TPM konektor 1x konektor reproduktoru a detekce otevření skříně

Porty na zadním panelu 1x PS/2 port myši 1x PS/2 port klávesnice 1x HDMI 1x DVI-D 1x VGA 4x USB 2.0 2x USB 3.2 Gen1 (USB 3.0) 1x RJ-45 3x audio jack

Rozměry 22,6 x 18,8 cm Micro ATX formát
