ASUS ProArt X670E-CREATOR WIFI/AM5/ATX

CPU AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors* * Refer to www.asus.com for CPU support list. Chipset AMD X670 Paměť 4 x DIMM, Max. 192GB, DDR5 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC & Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture Supports AMD Extended Profiles for Overclocking (EXPO™) OptiMem II * Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list. ** Non-ECC, Un-buffered DDR5 Memroy supports On-Die ECC function. Grafika 1 x HDMI® port** 2 x USB4® ports support USB Type-C® display outputs*** * Graphics specifications may vary between CPU types. ** Supports 4K@60Hz as specified in HDMI 2.1. *** Supports max. 8K@60Hz as specified in DisplayPort 1.4. **** Output at USB4_EC1 and USB4_EC2, each requires a USB-C® to DisplayPort adapter cable. VGA resolution support depends on processors' or graphic cards' resolution. Rozšiřující sloty AMD Ryzen™ 7000 Series Desktop Processors* 2 x PCIe 5.0 x16 slots (support x16 or x8/x8 modes) AMD X670 Chipset 1 x PCIe 4.0 x16 slot (supports x2 mode)** * Please check the PCIe bifurcation table in support site (https://www.asus.com/support/FAQ/1037507/). ** PCIEX16_3 shares bandwidth with M.2_3 slot. Please adjust in BIOS setting to enable PCIEX16_3. - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals. Úložiště Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports* AMD Ryzen™ 7000 Series Desktop Processors M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) AMD X670 Chipset M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)** M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports *AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10. ** M.2_3 slot shares bandwidth with PCIEX16_3. When PCIEX16_3 is in operation after adjusting in BIOS settings, M.2_3 slot will only run at PCIe x2 mode. Ethernet 1 x Marvell® AQtion 10Gb Ethernet 1 x Intel® 2.5Gb Ethernet ASUS LANGuard Bezdrátové připojení a Bluetooth Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth® v5.2 * WiFi 6E 6GHz regulatory may vary between countries. USB Rear USB (Total 11 ports) 2 x USB4® with Intel® JHL8540 USB4® controller ports (2 x USB Type-C®) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®) 7 x USB 3.2 Gen 2 ports (7 x Type-A) 1 x USB 2.0 port (1 x Type-A) Front USB (Total 9 ports) 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C® with up to 60W PD/QC4+) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 3 x USB 2.0 headers support 6 additional USB 2.0 ports Audio Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC* - Impedance sense for front and rear headphone outputs - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) - Supports up to 32-Bit/192 kHz playback* Audio Features - Power pre-regulator reduces power input noise to ensure consistent performance - Premium audio capacitors - Dedicated audio PCB layers - Audio cover - Unique de-pop circuit * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio. ** A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. Porty na zadním panelu 2 x USB4® with Intel® JHL8540 USB4® controller ports (2 x USB Type-C®) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®) 7 x USB 3.2 Gen 2 ports (7 x Type-A) 1 x USB 2.0 port (1 x Type-A) 1 x DisplayPort (Input only) 1 x HDMI® port 1 x Wi-Fi Module 1 x Marvell® AQtion 10Gb Ethernet 1 x Intel® 2.5Gb Ethernet 3 x Audio jacks 1 x BIOS FlashBack™ button Interní konektory Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 5 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 2 x 8-pin +12V Power connectors 1 x 6-pin PCIe Power connector Storage related 4 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C®) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 3 x USB 2.0 headers support 6 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x COM Port header 1 x CPU Over Voltage jumper 1 x Front Panel Audio header (AAFP) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thermal Sensor header Speciální funkce ASUS 5X PROTECTION III - DIGI+ VRM (- Digital power design) - Enhanced DRAM Overcurrent Protection - ESD Guards - LANGuard - Overvoltage Protection - Safeslot - Stainless-Steel Back I/O ASUS Q-Design - M.2 Q-Latch - PCIe Slot Q-Release - Q-Connector - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink backplate - M.2 heatsinks - VRM heatsink design ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - ProCool - Pre-mounted I/O shield - SafeSlot - SafeDIMM AURA Sync - Aura RGB header - Addressable Gen 2 headers Bespoke Motherboard Design & Business Focused Features - 24/7 Reliability - Overcurrent Protection Front Panel USB 3.2 Gen 2x2 with Quick Charge 4+ Support - Support: up to 60W charging* - Output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A - Compatible with QC 4.0/3.0/2.0, PD3.0 and PPS * To support 60W, please install the power cable to 6-pin PCIe Graphics Card connector or can only support 27W Softwarové funkce ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Fan Xpert 4 with AI Cooling II - Power Saving - Two-Way AI Noise Cancellation AI Suite 3 TPU DIGI+ VRM Turbo app ASUS CPU-Z IT Management software supported - ASUS Control Center Express(ACCE) CreationFirst MyAsus Norton Anti-virus software (Free Trial version) ProArt Creator Hub WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode FlexKey BIOS 256 Mb Flash ROM, UEFI AMI BIOS Správa WOL by PME, PXE Příslušenství Cables 1 x DisplayPort cable 4 x SATA 6Gb/s cables Miscellaneous 1 x ASUS Wi-Fi moving antennas 1 x Q-connector 1 x M.2 Q-Latch package for M.2 backplate 2 x Rubber Packages for M.2 1 x Rubber Package for M.2 backplate 1 x Screw packages for M.2 SSD 1 x ProArt ruler Documentation 1 x ACC Express Activation Key Card 1

CPU AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors* * Refer to www.asus.com for CPU support list. Chipset AMD X670 Paměť 4 x DIMM, Max. 192GB, DDR5 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC & Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture Supports AMD Extended Profiles for Overclocking (EXPO™) OptiMem II * Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list. ** Non-ECC, Un-buffered DDR5 Memroy supports On-Die ECC function. Grafika 1 x HDMI® port** 2 x USB4® ports support USB Type-C® display outputs*** * Graphics specifications may vary between CPU types. ** Supports 4K@60Hz as specified in HDMI 2.1. *** Supports max. 8K@60Hz as specified in DisplayPort 1.4. **** Output at USB4_EC1 and USB4_EC2, each requires a USB-C® to DisplayPort adapter cable. VGA resolution support depends on processors' or graphic cards' resolution. Rozšiřující sloty AMD Ryzen™ 7000 Series Desktop Processors* 2 x PCIe 5.0 x16 slots (support x16 or x8/x8 modes) AMD X670 Chipset 1 x PCIe 4.0 x16 slot (supports x2 mode)** * Please check the PCIe bifurcation table in support site (https://www.asus.com/support/FAQ/1037507/). ** PCIEX16_3 shares bandwidth with M.2_3 slot. Please adjust in BIOS setting to enable PCIEX16_3. - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals. Úložiště Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports* AMD Ryzen™ 7000 Series Desktop Processors M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) AMD X670 Chipset M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)** M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports *AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10. ** M.2_3 slot shares bandwidth with PCIEX16_3. When PCIEX16_3 is in operation after adjusting in BIOS settings, M.2_3 slot will only run at PCIe x2 mode. Ethernet 1 x Marvell® AQtion 10Gb Ethernet 1 x Intel® 2.5Gb Ethernet ASUS LANGuard Bezdrátové připojení a Bluetooth Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth® v5.2 * WiFi 6E 6GHz regulatory may vary between countries. USB Rear USB (Total 11 ports) 2 x USB4® with Intel® JHL8540 USB4® controller ports (2 x USB Type-C®) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®) 7 x USB 3.2 Gen 2 ports (7 x Type-A) 1 x USB 2.0 port (1 x Type-A) Front USB (Total 9 ports) 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C® with up to 60W PD/QC4+) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 3 x USB 2.0 headers support 6 additional USB 2.0 ports Audio Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC* - Impedance sense for front and rear headphone outputs - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) - Supports up to 32-Bit/192 kHz playback* Audio Features - Power pre-regulator reduces power input noise to ensure consistent performance - Premium audio capacitors - Dedicated audio PCB layers - Audio cover - Unique de-pop circuit * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio. ** A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. Porty na zadním panelu 2 x USB4® with Intel® JHL8540 USB4® controller ports (2 x USB Type-C®) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®) 7 x USB 3.2 Gen 2 ports (7 x Type-A) 1 x USB 2.0 port (1 x Type-A) 1 x DisplayPort (Input only) 1 x HDMI® port 1 x Wi-Fi Module 1 x Marvell® AQtion 10Gb Ethernet 1 x Intel® 2.5Gb Ethernet 3 x Audio jacks 1 x BIOS FlashBack™ button Interní konektory Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 5 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 2 x 8-pin +12V Power connectors 1 x 6-pin PCIe Power connector Storage related 4 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C®) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 3 x USB 2.0 headers support 6 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x COM Port header 1 x CPU Over Voltage jumper 1 x Front Panel Audio header (AAFP) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thermal Sensor header Speciální funkce ASUS 5X PROTECTION III - DIGI+ VRM (- Digital power design) - Enhanced DRAM Overcurrent Protection - ESD Guards - LANGuard - Overvoltage Protection - Safeslot - Stainless-Steel Back I/O ASUS Q-Design - M.2 Q-Latch - PCIe Slot Q-Release - Q-Connector - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink backplate - M.2 heatsinks - VRM heatsink design ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - ProCool - Pre-mounted I/O shield - SafeSlot - SafeDIMM AURA Sync - Aura RGB header - Addressable Gen 2 headers Bespoke Motherboard Design & Business Focused Features - 24/7 Reliability - Overcurrent Protection Front Panel USB 3.2 Gen 2x2 with Quick Charge 4+ Support - Support: up to 60W charging* - Output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A - Compatible with QC 4.0/3.0/2.0, PD3.0 and PPS * To support 60W, please install the power cable to 6-pin PCIe Graphics Card connector or can only support 27W Softwarové funkce ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Fan Xpert 4 with AI Cooling II - Power Saving - Two-Way AI Noise Cancellation AI Suite 3 TPU DIGI+ VRM Turbo app ASUS CPU-Z IT Management software supported - ASUS Control Center Express(ACCE) CreationFirst MyAsus Norton Anti-virus software (Free Trial version) ProArt Creator Hub WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode FlexKey BIOS 256 Mb Flash ROM, UEFI AMI BIOS Správa WOL by PME, PXE Příslušenství Cables 1 x DisplayPort cable 4 x SATA 6Gb/s cables Miscellaneous 1 x ASUS Wi-Fi moving antennas 1 x Q-connector 1 x M.2 Q-Latch package for M.2 backplate 2 x Rubber Packages for M.2 1 x Rubber Package for M.2 backplate 1 x Screw packages for M.2 SSD 1 x ProArt ruler Documentation 1 x ACC Express Activation Key Card 1

ASUS ProArt X670E-CREATOR WIFI Chipset: AMD X670 Rozměrový formát: ATX 30,5x24,4cm Podpora pro procesory: AMD Ryzen™ řady 7000 Patice procesoru: AM5 Paměť: * 4x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800, ECC a bez ECC, bez vyrovnávací paměti * dvoukanálová architektura paměti * podporuje AMD EXtended Profiles for Overclocking (EXPO™) OptiMem II Grafické výstupy: * 2x USB4 ® podporují výstupy displeje USB Type-C® * 1x DisplayPort 1.4 (vstup) * 1x HDMI® 2.1 Zvuková karta: Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC Ethernet: 1x Marvell® AQtion 10Gb, 1x Intel® 2,5Gb, ASUS LANGuard WLAN + Bluetooth: 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax), podporuje frekvenční pásmo 2,4/5GHz + Bluetooth v5.2 Rozšiřující sloty: * 2x slot PCIe 5.0 x16 (podpora režimů x16 nebo x8/x8) * 1x slot PCIe 4.0 x16 (podporuje režim x2) RAID řadič: technologie AMD RAID Xpert2 podporuje NVMe RAID 0/1/10 i SATA RAID 0/1/10 Úložný prostor: celkem podporuje 4 sloty M.2 a 4 porty SATA 6Gb/s * 1x M.2_1 (Key M), typ 2242/2260/2280 (podporuje režim PCIe 5.0 x4) * 1x M.2_2 (Key M), typ 2242/2260/2280 (podporuje režim PCIe 5.0 x4) * 1x M.2_3 (Key M), typ 2242/2260/2280 (podporuje režim PCIe 4.0 x4) * 1x M.2_4 (Key M), typ 2242/2260/2280/22110 (podporuje režim PCIe 4.0 x4) * 4x port SATA 6Gb/s USB: Zadní USB (celkem 11 portů) * 2x USB4® s Intel® JHL8540 USB4® (2x USB Type-C®) * 1x USB 3.2 Gen 2x2 (1x USB Type-C®) * 7x USB 3.2 Gen 2 (7x Type-A) * 1x USB 2.0 (1x Type-A) Přední USB (celkem 9 portů) * 1x USB 3.2 Gen 2x2 konektor (podporuje USB Type-C® s až 60W PD/QC4+) * 1x USB 3.2 Gen 1 header podporuje 2 další porty USB 3.2 Gen 1 * 3x USB 2.0 header podporuje 6 dalších USB 2.0 portů Porty na zadním panelu: * 2x USB4® s řadičem Intel® JHL8540 USB4® (2x USB Type-C®) * 1x USB 3.2 Gen 2x2 (1x USB Type-C®) * 7x USB 3.2 Gen 2 (7x Type-A) * 1x USB 2.0 (1x Type-A) * 1x DisplayPort (pouze vstup) * 1x HDMI® * 1x Wi-Fi modul * 1x Marvell® AQtion 10Gb Ethernet * 1x Intel® 2,5Gb Ethernet * 3x audio konektor * 1x tlačítko BIOS FlashBack™ Interní porty: Související s ventilátorem a chlazením * 1x 4-pin CPU Fan header * 1x 4-pin CPU OPT Fan header * 1x 4-pin header AIO Pump * 5x 4-pin header Chassis Fan Napájení * 1x 24-pin hlavní napájecí konektor * 2x 8-pin +12V napájecí konektor * 1x 6-pin PCIe napájecí konektor Související s úložištěm * 4x M.2 slot (Key M) * 4x SATA 6Gb/s port USB * 1x USB 3.2 Gen 2x2 konektor (podporuje USB Type-C®) * 1x USB 3.2 Gen 1 header podporuje 2 další porty USB 3.2 Gen 1 * 3x header USB 2.0 podporuje dalších 6 portů USB 2.0 Ostatní * 3x adresovatelný Gen 2 header * 1x Aura RGB header * 1x Clear CMOS header * 1x COM Port header * 1x CPU Over Voltage jumper * 1x Front Panel Audio header (AAFP) * 1x 20-3 pin System Panel header s funkcí Chassis Intrude * 1x header tepelného senzoru BIOS: 256Mb Flash ROM, UEFI AMI BIOS Příslušenství: * 1x kabel DisplayPort * 4x SATA 6Gb/s kabel * 1x ASUS Wi-Fi anténa * 1x M.2 Q-Latch balení pro M.2 backplate * 2x balení podložek pro M.2 * 1x balení podložek pro M.2 backplate * 1x balení šroubů pro M.2 SSD * 1x Q-konektor * 1x pravítko ProArt * 1x uživatelská příručka * 1x ACC Express Activation Key Card Odkaz na stránku výrobce: https://www.asus.com/Motherboards-Components/Motherboards/ProArt/ProArt-X670E-CREATOR-WIFI/

ASUS ProArt X670E-CREATOR WIFI

Deska je vybavena grafickými výstupy pro použití s procesory s integrovaným grafickým jádrem. Základní deska grafickou kartu neobsahuje a bez použití odpovídajícího procesoru, budou tyto výstupy nefunkční.

CPU Podpora procesorů AMD Ryzen série 7000 (patice AM5)

Čipová sada AMD X670

Paměť 4× DDR5 paměťový slot, podpora až 192 GB Podpora DDR5 8000+(OC)/ 7800 (OC)/ 7600 (OC)/ 7200 (OC)/ 7000 (OC)/ 6800 (OC)/ 6600 (OC)/ 6400 (OC)/ 6200 (OC)/ 6000 (OC)/ 5800 (OC)/ 5600 (OC)/ 5400 (OC)/ 5200/ 5000/ 4800 MHz Dvoukanálová architektura paměti Podpora ECC a non-ECC, bez vyrovnávací paměti Podpora On-Die ECC funkce Podpora AMD EXtended Profiles for Overclocking (EXPO) Podpora OptiMem II

Sloty AMD CPU 2× PCIe 5.0 x16 slot (podporuje x16 nebo x8/x8 režim) AMD X670 čipová sada 1× PCIe 4.0 x16 slot (podporuje x2 režim)

Grafika 1× HDMI 2.1 port, podporující max. rozlišení 4K při 60 Hz 1× DisplayPort 1.4 port, podporující max. rozlišení 8K při 60 Hz

Úložiště AMD CPU 2× M.2 slot, M Key, pro jednotky typu 2242/2260/2280 (PCIe 5.0 x4 režim) AMD X670 čipová sada 1× M.2 slot, M Key, pro jednotky typu 2242/2260/2280 (PCIe 4.0 x4 režim) 1× M.2 slot, M Key, pro jednotky typu 2242/2260/2280/22110 (PCIe 4.0 x4 režim) 4× SATA 6Gb/s port Podpora RAID 0, RAID 1 a RAID 10 pro NVMe a SATA jednotky Podpora AMD RAIDXpert2 technologie

USB 2× USB-C 4.0 porty na zadním panelu 2× USB-C 3.2 Gen 2×2 (USB 3.2) port (1 port na zadním panelu, 1 port dostupný přes interní USB konektor) 7× USB 3.2 Gen2 (USB 3.1) porty na zadním panelu 2× USB 3.2 Gen1 (USB 3.0) port dostupný přes interní USB konektor 7× USB 2.0 (1 port na zadním panelu, 6 portů dostupných přes interní USB konektor)

Audio Realtek S1220A 7.1kanálové High Definition Audio

LAN 1× Marvell AQtion 10GbE LAN řadič 1× Intel 2,5GbE LAN řadič ASUS LANGuard

WLAN/ Bluetooth Wi-Fi 6E Wi-Fi 802.11a/b/g/n/ac/ax Triple Band (2,4 GHz, 5 GHz, 6 GHz) Bluetooth 5.2

Interní konektory 1× 24pin hlavní napájecí konektor 2× 8pin 12V napájecí konektor 1× 6pin PCIe napájecí konektor 1× 4pin konektor ventilátoru CPU 1× 4pin konektor volitelného ventilátoru CPU 1× 4pin konektor pumpy vodního chlazení 5× 4pin konektor ventilátoru skříně 4× M.2 slot, M Key 4× SATA konektor 1× USB-C 3.2 Gen2×2 konektor 1× USB 3.2 Gen1 (USB 3.0) konektor (podporuje 2× USB 3.2 Gen1 port) 3× USB 2.0 konektor (podporuje 6× USB 2.0 port) 3× adresovatelný Gen2 konektor 1× konektor Aura RGB LED pásku 1× konektor Clear CMOS 1× audio konektor předního panelu 1× konektor sériového portu 1× jumper přepětí CPU 1× konektor systémového panelu a detekce otevření skříně 1× konektor teplotního senzoru

Porty na zadním panelu 1× HDMI 1× DisplayPort 2× USB-C 4.0 1× USB-C 3.2 Gen 2×2 (USB 3.2) 7× USB 3.2 Gen2 (USB 3.1) 1× USB 2.0 2× RJ-45 2× konektor Wi-Fi antény 3× audio jack 1× tlačítko BIOS Flashback

Rozměry 30,5 × 24,4 cm ATX formát

ProArt X670E-Creator WiFi umožňuje tvorcom všetkých úrovní maximalizovať výkon najnovších procesorov AMD Ryzen™ 7000 Series s 16+2 tímovými výkonovými stupňami, DDR5 a PCIe 5.0 a bleskovo rýchlym pripojením vrátane USB4®, 10 Gb a 2,5 Gb. Ethernet a WiFi 6E. Prejavuje profesionálnu, elegantnú a precíznu víziu pre tvorcov obsahu každého druhu so štýlom povýšeným vrstvami čiernej farby tón v tóne s kovovými zlatými prvkami. Priesvitný I/O kryt tiež poskytuje užívateľom štýlový pohľad na prémiové konektory vo vnútri. CPU AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors* * Refer to www.asus.com for CPU support list. Chipset AMD X670 Memory 4 x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC & Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture Supports AMD Extended Profiles for Overclocking (EXPO™) OptiMem II * Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list. ** Non-ECC, Un-buffered DDR5 Memroy supports On-Die ECC function. Graphics 1 x HDMI® port** 2 x USB4® ports support USB Type-C® display outputs*** * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. ** Supports 4K@60Hz as specified in HDMI 2.1. *** Supports max. 8K@60Hz as specified in DisplayPort 1.4. **** Output at USB4_EC1 and USB4_EC2, each requires a USB-C® to DisplayPort adapter cable. VGA resolution support depends on processors' or graphic cards' resolution. Expansion Slots AMD Ryzen™ 7000 Series Desktop Processors* 2 x PCIe 5.0 x16 slots (support x16 or x8/x8 modes) AMD X670 Chipset 1 x PCIe 4.0 x16 slot (supports x2 mode)** * Please check the PCIe bifurcation table in support site (https://www.asus.com/support/FAQ/1037507/). ** PCIEX16_3 shares bandwidth with M.2_3 slot. Please adjust in BIOS setting to enable PCIEX16_3. - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals. Storage Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports* AMD Ryzen™ 7000 Series Desktop Processors M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) AMD X670 Chipset M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)** M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports *AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10. ** M.2_3 slot shares bandwidth with PCIEX16_3. When PCIEX16_3 is in operation after adjusting in BIOS settings, M.2_3 slot will only run at PCIe x2 mode. Ethernet 1 x Marvell® AQtion 10Gb Ethernet 1 x Intel® 2.5Gb Ethernet ASUS LANGuard Wireless & Bluetooth Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth v5.2 * WiFi 6E 6GHz regulatory may vary between countries. Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth® v5.2 * WiFi 6E 6GHz regulatory may vary between countries. USB Rear USB (Total 11 ports) 2 x USB4® with Intel® JHL8540 USB4® controller ports (2 x USB Type-C®) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®) 7 x USB 3.2 Gen 2 ports (7 x Type-A) 1 x USB 2.0 port (1 x Type-A) Front USB (Total 9 ports) 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C® with up to 60W PD/QC4+) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 3 x USB 2.0 headers support 6 additional USB 2.0 ports Audio Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC* - Impedance sense for front and rear headphone outputs - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) - Supports up to 32-Bit/192 kHz playback* Audio Features - Power pre-regulator reduces power input noise to ensure consistent performance - Premium audio capacitors - Dedicated audio PCB layers - Audio cover - Unique de-pop circuit * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio. ** A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. Back Panel I/O Ports 2 x USB4® with Intel® JHL8540 USB4® controller ports (2 x USB Type-C®) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®) 7 x USB 3.2 Gen 2 ports (7 x Type-A) 1 x USB 2.0 port (1 x Type-A) 1 x DisplayPort (Input only) 1 x HDMI® port 1 x Wi-Fi Module 1 x Marvell® AQtion 10Gb Ethernet 1 x Intel® 2.5Gb Ethernet 3 x Audio jacks 1 x BIOS FlashBack™ button Internal I/O Connectors Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 5 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 2 x 8-pin +12V Power connectors 1 x 6-pin PCIe Power connector Storage related 4 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C®) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 3 x USB 2.0 headers support 6 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x COM Port header 1 x CPU Over Voltage jumper 1 x Front Panel Audio header (AAFP) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thermal Sensor header Special Features ASUS 5X PROTECTION III - DIGI+ VRM (- Digital power design) - Enhanced DRAM Overcurrent Protection - ESD Guards - LANGuard - Overvoltage Protection - Safeslot - Stainless-Steel Back I/O ASUS Q-Design - M.2 Q-Latch - PCIe Slot Q-Release - Q-Connector - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink backplate - M.2 heatsinks - VRM heatsink design ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - ProCool - Pre-mounted I/O shield - SafeSlot - SafeDIMM AURA Sync - Aura RGB header - Addressable Gen 2 headers Bespoke Motherboard Design & Business Focused Features - 24/7 Reliability - Overcurrent Protection Front Panel USB 3.2 Gen 2x2 with Quick Charge 4+ Support - Support: up to 60W charging* - Output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A - Compatible with QC 4.0/3.0/2.0, PD3.0 and PPS * To support 60W, please install the power cable to 6-pin PCIe Graphics Card connector or can only support 27W Software Features ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Fan Xpert 4 with AI Cooling II - Power Saving - Two-Way AI Noise Cancellation AI Suite 3 TPU DIGI+ VRM Turbo app ASUS CPU-Z IT Management software supported - ASUS Control Center Express(ACCE) CreationFirst MyAsus Norton Anti-virus software (Free Trial version) ProArt Creator Hub WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode FlexKey BIOS 256 Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PME, PXE Accessories Cables 1 x DisplayPort cable 4 x SATA 6Gb/s cables Miscellaneous 1 x ASUS Wi-Fi moving antennas 1 x Q-connector 1 x M.2 Q-Latch package for M.2 backplate 2 x Rubber Packages for M.2 1 x Rubber Package for M.2 backplate 1 x Screw packages for M.2 SSD 1 x ProArt ruler Documentation 1 x ACC Express Activation Key Card 1 x User guide Operating System Windows® 11 64-bit, Windows® 10 64-bit Form Factor ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

Parametr	Hodnota
Pro procesory	AMD
Socket (patice)	Socket AM5 (LGA 1718)
Chipset	AMD X670E
Počet paměťových slotů	4
Technologie paměti RAM	DDR5
Formát základní desky	ATX
PCI Express x16	2
SATA 3	4
M.2 slot	4
3.5mm Jack	Ano
LAN	10Gbit/s
HDMI	1
Bezdrátové připojení	WiFi + Bluetooth
COM port	Ano

Specifikace:

ProArt X670E-CREATOR WIFI

CPU	AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors*
	* Refer to www.asus.com for CPU support list.
Chipset	AMD X670
Memory	4 x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 ECC and Non-ECC, Un-buffered Memory*
	Dual Channel Memory Architecture
	Supports AMD EXTended Profiles for Overclocking (EXPO™)
	OptiMem II
	* Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.
	* Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function.
Graphics	1 x HDMI port**
	2 x USB4 ports support USB Type-C display outputs***
	* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
	** Supports 4K@60Hz as specified in HDMI 2.1.
	*** Supports max. 8K@60Hz as specified in DisplayPort 1.4.
	**** Output at USB4_EC1 and USB4_EC2, each requires a USB-C to DisplayPort adapter cable. VGA resolution support depends on processors' or graphic cards' resolution.
Expansion Slots	AMD Ryzen™ 7000 Series Desktop Processors*
	2 x PCIe 5.0 x16 slots (support x16 or x8/x8 modes)
	AMD X670 Chipset
	1 x PCIe 4.0 x16 slot (supports x2 mode)**
	* Please check the PCIe bifurcation table in support site (https://www.asus.com/support/FAQ/1037507/).
	** PCIEX16_3 shares bandwidth with M.2_3 slot. Please adjust in BIOS setting to enable PCIEX16_3.
Storage	Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*
	AMD Ryzen™ 7000 Series Desktop Processors
	M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
	M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
	AMD X670 Chipset
	M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)**
	M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
	4 x SATA 6Gb/s ports
	*AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10.
	** M.2_3 slot shares bandwidth with PCIEX16_3. When PCIEX16_3 is in operation after adjusting in BIOS settings, M.2_3 slot will only run at PCIe x2 mode.
Ethernet	1 x Marvell AQtion 10Gb Ethernet
	1 x Intel 2.5Gb Ethernet
	ASUS LANGuard
Wireless & Bluetooth	Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth v5.2 * WiFi 6E 6GHz regulatory may vary between countries.
USB	Rear USB (Total 11 ports)
	2 x USB4 with Intel JHL8540 USB4 controller ports (2 x USB Type-C)
	1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
	7 x USB 3.2 Gen 2 ports (7 x Type-A)
	1 x USB 2.0 port (1 x Type-A)
	Front USB (Total 9 ports)
	1 x USB 3.2 Gen 2x2 connector (supports USB Type-C with up to 60W PD/QC4+)
	1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
	3 x USB 2.0 headers support additional 6 USB 2.0 ports
Audio	Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC* - Impedance sense for front and rear headphone outputs - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) - Supports up to 32-Bit/192 kHz playback*
	Audio Features
	- Power pre-regulator reduces power input noise to ensure consistent performance
	- Premium audio capacitors
	- Dedicated audio PCB layers
	- Audio cover
	- Unique de-pop circuit
	* Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
	** A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Back Panel I/O Ports	2 x USB4 with Intel JHL8540 USB4 controller ports (2 x USB Type-C)
	1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
	7 x USB 3.2 Gen 2 ports (7 x Type-A)
	1 x USB 2.0 port (1 x Type-A)
	1 x DisplayPort (Input only)
	1 x HDMI port
	1 x Wi-Fi Module
	1 x Marvell AQtion 10Gb Ethernet
	1 x Intel 2.5Gb Ethernet
	3 x Audio jacks
	1 x BIOS FlashBack™ button
Internal I/O Connectors	Fan and Cooling related
	1 x 4-pin CPU Fan header
	1 x 4-pin CPU OPT Fan header
	1 x 4-pin AIO Pump header
	5 x 4-pin Chassis Fan headers
	Power related
	1 x 24-pin Main Power connector
	2 x 8-pin +12V Power connectors
	1 x 6-pin PCIe Power connector
	Storage related
	4 x M.2 slots (Key M)
	4 x SATA 6Gb/s ports
	USB
	1 x USB 3.2 Gen 2x2 connector (supports USB Type-C)
	1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
	3 x USB 2.0 headers support additional 6 USB 2.0 ports
	Miscellaneous
	3 x Addressable Gen 2 headers
	1 x Aura RGB header
	1 x Clear CMOS header
	1 x COM Port header
	1 x CPU Over Voltage jumper
	1 x Front Panel Audio header (AAFP)
	1 x 20-3 pin System Panel header with Chassis intrude function
	1 x Thermal Sensor header
Special Features	ASUS 5X PROTECTION III
	- DIGI+ VRM (- Digital power design)
	- Enhanced DRAM Overcurrent Protection
	- ESD Guards
	- LANGuard
	- Overvoltage Protection
	- Safeslot
	- Stainless-Steel Back I/O
	ASUS Q-Design
	- M.2 Q-Latch
	- PCIe Slot Q-Release
	- Q-Connector
	- Q-DIMM
	- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
	- Q-Slot
	ASUS Thermal Solution
	- M.2 heatsink backplate
	- M.2 heatsinks
	- VRM heatsink design
	ASUS EZ DIY
	- BIOS FlashBack™ button
	- BIOS FlashBack™ LED
	- ProCool
	- Pre-mounted I/O shield
	- SafeSlot
	- SafeDIMM
	AURA Sync
	- Aura RGB header
	- Addressable Gen 2 headers
	Bespoke Motherboard Design & Business Focused Features
	- 24/7 Reliability
	- Overcurrent Protection
	Front Panel USB 3.2 Gen 2x2 with Quick Charge 4+ Support
	- Support: up to 60W charging*
	- Output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A
	- Compatible with QC 4.0/3.0/2.0, PD3.0 and PPS
	* To support 60W, please install the power cable to 6-pin PCIe Graphics Card connector or can only support 27W
Software Features	ASUS Exclusive Software
	Armoury Crate
	- Aura Creator
	- Aura Sync
	- Fan Xpert 4 with AI Cooling II
	- Power Saving
	- Two-Way AI Noise Cancellation
	AI Suite 3
	TPU
	DIGI+ VRM
	Turbo app
	ASUS CPU-Z
	IT Management software supported
	- ASUS Control Center Express(ACCE)
	CreationFirst
	MyAsus
	Norton Anti-virus software (Free Trial version)
	ProArt Creator Hub
	WinRAR
	UEFI BIOS
	ASUS EZ DIY
	- ASUS CrashFree BIOS 3
	- ASUS EZ Flash 3
	- ASUS UEFI BIOS EZ Mode
	FlexKey
BIOS	256 Mb Flash ROM, UEFI AMI BIOS
Manageability	WOL by PME, PXE
Accessories	Cables
	1 x DisplayPort cable
	4 x SATA 6Gb/s cables
	Miscellaneous
	1 x ASUS Wi-Fi moving antennas
	1 x Q-connector
	1 x M.2 Q-Latch package for M.2 backplate
	2 x Rubber Packages for M.2
	1 x Rubber Package for M.2 backplate
	1 x Screw packages for M.2 SSD
	1 x ProArt ruler
	Documentation
	1 x ACC Express Activation Key Card
	1 x User guide
Operating System	Windows 11 64-bit
Form Factor	ATX Form Factor
	12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

ASUS ProArt X670E-CREATOR WIFI Chipset: AMD X670 Rozměrový formát: ATX 30,5x24,4cm Podpora pro procesory: AMD Ryzen™ řady 7000 Patice procesoru: AM5 Paměť: 4x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800, ECC a bez ECC, bez vyrovnávací paměti dvoukanálová architektura paměti podporuje AMD EXtended Profiles for Overclocking (EXPO™) OptiMem II Grafická karta: 2x USB4 ® podporují výstupy displeje USB Type-C® 1x DisplayPort 1.4 (vstup) 1x HDMI® 2.1 Zvuková karta: Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC Ethernet: 1x Marvell® AQtion 10Gb, 1x Intel® 2,5Gb, ASUS LANGuard WLAN + Bluetooth: 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax), podporuje frekvenční pásmo 2,4/5GHz + Bluetooth v5.2 Rozšiřující sloty: 2x slot PCIe 5.0 x16 (podpora režimů x16 nebo x8/x8) 1x slot PCIe 4.0 x16 (podporuje režim x2) RAID řadič: technologie AMD RAID Xpert2 podporuje NVMe RAID 0/1/10 i SATA RAID 0/1/10 Úložný prostor: celkem podporuje 4 sloty M.2 a 4 porty SATA 6Gb/s 1x M.2_1 (Key M), typ 2242/2260/2280 (podporuje režim PCIe 5.0 x4) 1x M.2_2 (Key M), typ 2242/2260/2280 (podporuje režim PCIe 5.0 x4) 1x M.2_3 (Key M), typ 2242/2260/2280 (podporuje režim PCIe 4.0 x4) 1x M.2_4 (Key M), typ 2242/2260/2280/22110 (podporuje režim PCIe 4.0 x4) 4x port SATA 6Gb/s USB: Zadní USB (celkem 11 portů) 2x USB4® s Intel® JHL8540 USB4® (2x USB Type-C®) 1x USB 3.2 Gen 2x2 (1x USB Type-C®) 7x USB 3.2 Gen 2 (7x Type-A) 1x USB 2.0 (1x Type-A) Přední USB (celkem 9 portů) 1x USB 3.2 Gen 2x2 konektor (podporuje USB Type-C® s až 60W PD/QC4+) 1x USB 3.2 Gen 1 header podporuje 2 další porty USB 3.2 Gen 1 3x USB 2.0 header podporuje 6 dalších USB 2.0 portů Porty na zadním panelu: 2x USB4® s řadičem Intel® JHL8540 USB4® (2x USB Type-C®) 1x USB 3.2 Gen 2x2 (1x USB Type-C®) 7x USB 3.2 Gen 2 (7x Type-A) 1x USB 2.0 (1x Type-A) 1x DisplayPort (pouze vstup) 1x HDMI® 1x Wi-Fi modul 1x Marvell® AQtion 10Gb Ethernet 1x Intel® 2,5Gb Ethernet 3x audio konektor 1x tlačítko BIOS FlashBack™ Interní porty: Související s ventilátorem a chlazením 1x 4-pin CPU Fan header 1x 4-pin CPU OPT Fan header 1x 4-pin header AIO Pump 5x 4-pin header Chassis Fan Napájení 1x 24-pin hlavní napájecí konektor 2x 8-pin +12V napájecí konektor 1x 6-pin PCIe napájecí konektor Související s úložištěm 4x M.2 slot (Key M) 4x SATA 6Gb/s port USB 1x USB 3.2 Gen 2x2 konektor (podporuje USB Type-C®) 1x USB 3.2 Gen 1 header podporuje 2 další porty USB 3.2 Gen 1 3x header USB 2.0 podporuje dalších 6 portů USB 2.0 Ostatní 3x adresovatelný Gen 2 header 1x Aura RGB header 1x Clear CMOS header 1x COM Port header 1x CPU Over Voltage jumper 1x Front Panel Audio header (AAFP) 1x 20-3 pin System Panel header s funkcí Chassis Intrude 1x header tepelného senzoru BIOS: 256Mb Flash ROM, UEFI AMI BIOS Příslušenství: 1x kabel DisplayPort 4x SATA 6Gb/s kabel 1x ASUS Wi-Fi anténa 1x M.2 Q-Latch balení pro M.2 backplate 2x balení podložek pro M.2 1x balení podložek pro M.2 backplate 1x balení šroubů pro M.2 SSD 1x Q-konektor 1x pravítko ProArt 1x uživatelská příručka 1x ACC Express Activation Key Card

ASUS ProArt X670E-CREATOR WIFI Chipset: AMD X670 Rozměrový formát: ATX 30,5x24,4cm Podpora pro procesory: AMD Ryzen™ řady 7000 Patice procesoru: AM5 Paměť: 4x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800, ECC a bez ECC, bez vyrovnávací paměti dvoukanálová architektura paměti podporuje AMD EXtended Profiles for Overclocking (EXPO™) OptiMem II Grafická karta: 2x USB4 ® podporují výstupy displeje USB Type-C® 1x DisplayPort 1.4 (vstup) 1x HDMI® 2.1 Zvuková karta: Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC Ethernet: 1x Marvell® AQtion 10Gb, 1x Intel® 2,5Gb, ASUS LANGuard WLAN + Bluetooth: 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax), podporuje frekvenční pásmo 2,4/5GHz + Bluetooth v5.2 Rozšiřující sloty: 2x slot PCIe 5.0 x16 (podpora režimů x16 nebo x8/x8) 1x slot PCIe 4.0 x16 (podporuje režim x2) RAID řadič: technologie AMD RAID Xpert2 podporuje NVMe RAID 0/1/10 i SATA RAID 0/1/10 Úložný prostor: celkem podporuje 4 sloty M.2 a 4 porty SATA 6Gb/s 1x M.2_1 (Key M), typ 2242/2260/2280 (podporuje režim PCIe 5.0 x4) 1x M.2_2 (Key M), typ 2242/2260/2280 (podporuje režim PCIe 5.0 x4) 1x M.2_3 (Key M), typ 2242/2260/2280 (podporuje režim PCIe 4.0 x4) 1x M.2_4 (Key M), typ 2242/2260/2280/22110 (podporuje režim PCIe 4.0 x4) 4x port SATA 6Gb/s USB: Zadní USB (celkem 11 portů) 2x USB4® s Intel® JHL8540 USB4® (2x USB Type-C®) 1x USB 3.2 Gen 2x2 (1x USB Type-C®) 7x USB 3.2 Gen 2 (7x Type-A) 1x USB 2.0 (1x Type-A) Přední USB (celkem 9 portů) 1x USB 3.2 Gen 2x2 konektor (podporuje USB Type-C® s až 60W PD/QC4+) 1x USB 3.2 Gen 1 header podporuje 2 další porty USB 3.2 Gen 1 3x USB 2.0 header podporuje 6 dalších USB 2.0 portů Porty na zadním panelu: 2x USB4® s řadičem Intel® JHL8540 USB4® (2x USB Type-C®) 1x USB 3.2 Gen 2x2 (1x USB Type-C®) 7x USB 3.2 Gen 2 (7x Type-A) 1x USB 2.0 (1x Type-A) 1x DisplayPort (pouze vstup) 1x HDMI® 1x Wi-Fi modul 1x Marvell® AQtion 10Gb Ethernet 1x Intel® 2,5Gb Ethernet 3x audio konektor 1x tlačítko BIOS FlashBack™ Interní porty: Související s ventilátorem a chlazením 1x 4-pin CPU Fan header 1x 4-pin CPU OPT Fan header 1x 4-pin header AIO Pump 5x 4-pin header Chassis Fan Napájení 1x 24-pin hlavní napájecí konektor 2x 8-pin +12V napájecí konektor 1x 6-pin PCIe napájecí konektor Související s úložištěm 4x M.2 slot (Key M) 4x SATA 6Gb/s port USB 1x USB 3.2 Gen 2x2 konektor (podporuje USB Type-C®) 1x USB 3.2 Gen 1 header podporuje 2 další porty USB 3.2 Gen 1 3x header USB 2.0 podporuje dalších 6 portů USB 2.0 Ostatní 3x adresovatelný Gen 2 header 1x Aura RGB header 1x Clear CMOS header 1x COM Port header 1x CPU Over Voltage jumper 1x Front Panel Audio header (AAFP) 1x 20-3 pin System Panel header s funkcí Chassis Intrude 1x header tepelného senzoru BIOS: 256Mb Flash ROM, UEFI AMI BIOS Příslušenství: 1x kabel DisplayPort 4x SATA 6Gb/s kabel 1x ASUS Wi-Fi anténa 1x M.2 Q-Latch balení pro M.2 backplate 2x balení podložek pro M.2 1x balení podložek pro M.2 backplate 1x balení šroubů pro M.2 SSD 1x Q-konektor 1x pravítko ProArt 1x uživatelská příručka 1x ACC Express Activation Key Card
